Model/Part Number: DWE-E3DWBR1

contact sales@dwe.ai for more customization information

Introducing the world's first real-time stereo camera that boasts a total resolution of 4MP and a Global Shutter sensor all through USB 2.0 output. It features Frame-Sync capability with microsecond accuracy. All of these features in a familiar easy-to-use package with an impressive 1000, 6000, or 12,000 meter water-depth rating.

Utilizing 2x stellarHD cameras on a precision calibrated bracket -- equipped with a modern Global Shutter sensor and a proprietary PCB, you will be able to capture synchronized video like never before. Using our frame-syncing technology, capture simultaneously-synchronized video at 60 FPS.

Furthermore, due to its UVC compliant nature, the explore3D is the first plug and play stereo vision capable subsea system. This makes the explore3D the perfect choice for anyone looking to make a modern 3D-data-capture system.

Fit For
Remotely Operated Vehicles (ROVs)
Autonomous Underwater Vehicles (AUVs)
Autonomous Surface Vehicles (ASVs)
Aquaculture Systems
Aquarium Camera Array
Weather-resistant Unmanned Aerial Vehicles (UAVs)
Aerial Drones
...and more!

3D from Hex to Decimal is 61!

Technical Data

Model/Part Number: DWE-E3DWBR1

• Resolution: 3200x1200 (2x | 1600x1200 RGB frames)
• Framerate: 60FPS
• Sensor: 2x stellarHD | 2MP RGB Global Shutter
• Lens: Proprietary Non-Distortion Aquagon Lens
• Baseline (Center to Center Distance): 150mm
• Power: <3 watts
• 2x USB 2.0 output

NDAA Compliant

Lens Specs

Lens Specifications Here

Learn More more about Aquagon

Contents

• 1x explore3D USB Camera

• Service and support to ingest real-time RGB frame data.
• Extrinsic Calibration Files for OpenCV and Other Computer Vision tools
